Boiler plate

Name: Boiler plate
Brand: SHIVA ALLOYS
Price: 250 INR
Availability: InStock

250 INR/Kilograms

Get a Price/Quote

Product Details:

Corrosion Resistant Yes, with proper coatings
Material Composition % C: 0.18-0.28%, Mn: 0.60-1.20%, Si: 0.15-0.35%, P: 0.035%, S: 0.035%
Hardness 125-180 HB
Recyclable Yes
Size Customizable to order, standard 1500/2000/2500 mm width, length up to 12000 mm
Tensile Strength 485-620 MPa (for A516 Gr.70)
Product Form Plate
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Boiler plate Price And Quantity

Minimum Order Quantity 100 Kilograms
Price 250 INR/Kilograms

Boiler plate Product Specifications

Grade IS 2062, ASTM A516 GR 60/70, EN 10028 P265GH/P355GH
Steel Type Carbon Steel
Tensile Strength 485-620 MPa (for A516 Gr.70)
Shape Rectangular
Material Grade A516 Grade 70/IS 2062 E250/E350, EN10028
Composition Carbon, Manganese, Phosphorus, Sulfur, Silicon
Product Form Plate
Finish Type Hot Rolled
Heat Resistance Yes
Weight Varies with size and thickness, generally 3000-8000 kg/plate
Diameter Not applicable (plate form)
Coating Type Can be supplied with primer or bare
Usage Primarily in boilers, pressure vessels, storage tanks
Corrosion Resistant Yes, with proper coatings
Application Boiler fabrication, pressure vessels, heat exchangers, industrial tanks, power plants
Surface Hot Rolled, smooth
Dimension (L*W*H) Custom sizes available, typical width 1500-2500 mm, length up to 12000 mm
Thickness 6 mm to 150 mm
Steel Product Type Steel Plates
Material Composition % C: 0.18-0.28%, Mn: 0.60-1.20%, Si: 0.15-0.35%, P: 0.035%, S: 0.035%
Steel Standard ASTM, ASME, EN, IS
Color Grey
Hardness 125-180 HB
Product Name Boiler Plate
Recyclable Yes
Size Customizable to order, standard 1500/2000/2500 mm width, length up to 12000 mm

Surface Protection Can be coated with anti-rust oil if required
Impact Resistance Charpy V-Notch tested at -20C
Edge Type Mill Edge, Cut Edge
Condition As rolled / normalized / stress relieved
Testing 100% Ultrasonic tested as per standard
Yield Strength 250 MPa min (A516 Gr.70)
Weldability Excellent weldability
Delivery Condition Ready stock or as per order
Density 7.85 g/cm3
Packing Details Packed in loose or as per customer requirement

Boiler plate Trade Information

Supply Ability 100000 Kilograms Per Month
Delivery Time 3 Days

Product Description

Select outstanding Boiler Plates with unparalleled quality and superior performance. Our Boiler Plates, made from best-in-class Carbon Steel (IS 2062, ASTM A516 GR 60/70, EN 10028 P265GH/P355GH), deliver a minimum yield strength of 250 MPa and excellent weldability. Each plate is 100% Ultrasonic tested as per standards, Charpy V-Notch tested at -20C, and available in as-rolled, normalized, or stress-relieved conditions. Shop now for mill or cut edge plates with surface protection options. Benefit from ready stock, custom sizing, rapid deal closures, and exceptional durability-ideal for power plants, pressure vessels, heat exchangers, and industrial tanks in India.

Material Excellence and Versatile Application

Boiler Plates offer an outstanding combination of mechanical properties and reliability. Engineered for demanding environments, these plates deliver excellent yield and tensile strength, making them the best choice for boiler fabrication and pressure vessels. Site applications include power plants, industrial tanks, and heat exchangers. Their specific use in critical safety equipment ensures general utility across diverse industrial sectors while providing peace of mind with rigorous quality controls and customizable dimensions to suit any project requirement.

Delivery, Packaging & Sample Availability

Boiler Plates are handed over at major Indian ports on an FOB basis, ensuring timely delivery and hassle-free logistics for global and domestic clients. Packing & Dispatch can be customized-packed loose or as per customer instructions-to secure and protect your plates during transit. Samples can be delivered on request, allowing clients to evaluate the quality before placing bulk orders. Efficient dispatch and responsive customer service ensure every order is fulfilled to satisfaction.

FAQ's of Boiler plate:

Q: How are the Boiler Plates tested for quality assurance?

A: Boiler Plates undergo 100% Ultrasonic testing and Charpy V-Notch impact testing at -20C to ensure structural integrity, along with compliance to ASTM, ASME, EN, and IS standards for weldability and mechanical performance.

Q: What is the process for ordering custom-sized Boiler Plates?

A: Customers can specify custom dimensions for length, width, and thickness. Upon selection, plates are manufactured accordingly and prepared for delivery as per order requirements.

Q: Where can Boiler Plates be applied for optimal performance?

A: These plates are designed for use in boiler fabrication, pressure vessels, heat exchangers, industrial tanks, and power plants, ensuring their best performance in environments requiring safety and durability.

Q: What are the benefits of selecting A516 Gr.70 Boiler Plates for pressure vessels?

A: A516 Gr.70 plates offer excellent weldability, high yield and tensile strength, and superior impact resistance, making them ideal for pressure vessels where strength and reliability are critical.

Q: How are Boiler Plates packed and delivered to clients?

A: Plates are packed loosely or as per customer specifications, shipped from major Indian FOB ports, and can include anti-rust oil coatings or primer for enhanced protection during transit.

Q: When can customers expect their Boiler Plate orders to be dispatched?

A: Boiler Plates are available in ready stock for immediate dispatch, or manufactured to order based on customer specifications. Lead times may vary depending on customization needs.
